| P/N | SP-750PCBxx |
|---|---|
| watts | 750W |
| RGB вентилятор | Нет |
| Форм фактор | ATX |
| Модель | SP-750AH3NCB-A |
| Тип | ATX 12V v2.4 and EPS v2.92 |
| Max. Output Capacity | 750W |
| Peak Output Capacity | 900W |
| ЦВЕТ | Black |
| Dimension ( W / H / D ) | 150mm(W) x 86mm(H) x 160mm(D) |
| PFC (Power Factor Correction) | Active PFC |
| Power Good Signal | 100-500 msec |
| Hold Up Time | > 16msec at 80% of full load |
| Input Current | 10A |
| Input Frequency Range | 47Hz -63Hz |
| Input Voltage | 100V-240V~ |
| Operating Temperature | 0°C to +40°C |
| Operating Humidity | 20% to 90%,non-condensing |
| Storage Temperature | -20 °C to +70 °C |
| Storage Humidity | 5% to 95%, non-condensing |
| СИСТЕМА ОХЛАЖДЕНИЯ | 140mm Fan: 1800 R.P.M. ± 10% |
| Efficiency | Meet 80 PLUS®Bronze at 115Vac input. |
| MTBF | 100,000 hrs minimum |
| Safety Approval | UL/CUL/TUV/CE/FCC and BSMI |
| PCI-E 6+2pin | PCI-E 6+2pin x 4 |
User Manual
- Имя файла
- Описание
- Размер
- Version
- Release Date
-
Manual
- Multi-language
- 11.4 MB
- 2016-10-26
