P/N | TPG-0650M |
---|---|
watts | 650W |
RGB вентилятор | Нет |
Форм фактор | ATX |
Модель | TPG-650AH3FCG |
Тип | Intel ATX 12V V2.3 & EPS 12V standards |
Max. Output Capacity | 650W |
Peak Output Capacity | 780W |
ЦВЕТ | Black |
PFC (Power Factor Correction) | Active PFC |
Power Good Signal | 100-500 msec |
Hold Up Time | 16msec (minimum) @ 80% of full load at 115 / 230Vac input. |
Input Current | 10A / 5A |
Input Frequency Range | 50 Hz - 60 Hz |
Input Voltage | 100 Vac- 240 Vac |
Operating Temperature | 0℃ to +50℃ |
Operating Humidity | 20% to 90%,non-condensing |
Storage Temperature | -20 ℃ to +70 ℃ |
Storage Humidity | 5% to 95%, non-condensing |
СИСТЕМА ОХЛАЖДЕНИЯ | 140mm Fan |
Efficiency | 87-92% efficiency @ 20-100% load |
MTBF | 120,000 hrs minimum |
Safety Approval | UL/ TUV/ CE/ FCC/ BSMI/ GOST certification |
PCI-E 6+2pin | PCI-E 6+2pin x 4 |
